Cover more ground with ease. Our 12v tape can extend to a whopping 12.8 meters using only a single power supply.
Stand out with confidence. An output of 420 lumens per meter ensures that this is the most powerful black tape there is.
A designer’s dream when it comes to large-scale applications. And with three addressable LEDs per pixel, that means less time spent mapping, and more time being creative.
You’ve probably noticed that most LED tapes are white in colour.
While there are advantages to this for certain applications, a black printed circuit board is the best way to minimise external light reflection and conceal the workings of your installation when the display is switched off. It’s the stuff that a stealth designer’s dreams are made of.
Black PCB also absorbs and dissipates heat from LED chips more efficiently than standard white solder mask. We’ve used superior thickened copper tracks to reduce the effects of volt drop and to allow a more even intensity along the length of the strip. And with 20 individually-addressable pixels per meter, each capable of producing a 32-bit True Color display (4,294,967,296 variations) – this tape is ideal for both stage and architectural applications.
Precision-designed and manufactured to ENTTEC’s rigorous standards, some of our busiest professional clientele have been requesting we manufacture this tape for years. We’re delighted to have finally done so, and we think you’ll enjoy exploring the Dark Side too.
While it shares some of the same high-quality electronics that you’ve come to know and rely on from our other tapes, the black PCB makes this one special. We would say that it makes this tape stand out … but that’s precisely what it doesn’t do.
A clever designer will often want to use shadows and dark recesses to hide the inner workings of an installation in order to take an audience by surprise when the creation comes alive. This tape is perfect for that sort of thing. And fear not: it also looks good when it’s on!
60 RGBW LEDs per meter
It boasts 20 color-calibrated, addressable, RGBW Pixels per meter. Each Pixel is patched with three RGBW LEDS, and offers consistent brightness and extended color gamut.
Built for performance
Superior thickened copper tracks to reduce the effects of volt drop and to allow a more even intensity along the length of the strip.
Bright and super-efficient
With a maximum power consumption of only 19.7 watts per meter (RGBW all on), and a lumen capacity of 511 lumens per meter, this 12V tape provides a bright and efficient package.
Millions of colors
Each pixel can achieve a 32-bit, True Color display. That’s a whopping 4,294,967,296 possible colors for each LED chip, with a scan frequency not less than 1.5KHz per second.
Extend as you please
Join two lengths together or cut them into a smaller length. You can also operate the tape from up to 300m away using the ENTTEC Pixel Link system. This tape is recommended for indoor use only.
Ethernet to Pixel Link Driver - control up to 24,576 LED channels (8,192 RGB pixels).
An 8-port Ethernet-pixel controller, a compact version of the Pixelator. Powerful enough to control up to 8,192 channels (2,730 RGB pixels) with perfect synchronisation across all eight of its outputs.
PSAT: pixel power supply
With our new Pixel power supply device, you can easily power up and inject data to pixel strip and dot, without the need of an external power supply. Connect your lights using a connector and a driver (such as the Pixelator). Perfectly suited for both the live event and installation markets.
