With its rich, color-changing LED pixels housed within a bendable silicone strip, our professional Neon Flex is one of the most versatile light fixtures imaginable.
Flexible LED strip lighting.
Introducing ENTTEC Neon Flex: the ultimate lighting solution that combines flexibility, durability, and ease of installation. Made from high quality silicone, this waterproof LED strip is designed to handle any environment.
With its ability to bend horizontally, ENTTEC Neon Flex allows for easy shaping and contouring, enabling you to create amazing, unique designs.
Installing Neon Flex is a breeze with our range of cable and power connector options. In addition, with accessories for surface or recessed mounting, Neon Flex ensures a sleek and professional finish.
Precision engineered + proudly made in Australia.
- For professional applications
- 24V DMX or 12V SPI versions available
- Color-changing LED pixels
- Rich hues & ultra-smooth dimming
- Custom lengths made to order
E N T T E C Neon Flex is widely compatible with software
and lighting control systems from other popular brands.
So many possibilities.
LED Neon Flex is ideal for both indoor and outdoor lighting. Its versatile, durable and energy-saving nature lends itself perfectly to eye-catching signage or commercial building façades, not to mention multiple uses around your home.
You can also install it in cars, ships, museums, theme parks, nightclubs, concert venues … you name it. And when used alongside ENTTEC’s DMX or LED pixel controllers and software, your audience will be blown away.
Talk to us today and discover how ENTTEC’s professional Neon Flex can transform your project.
|LED source Epistar SMD LED 5050|
|Color RGBW (4000K)|
|LED lifetime 70,000 hours L70 @ 25°C / 50,000 hours L70 @ 50°C|
|Body material Silicone|
|Minimum bendable diameter 80mm|
|Beam angle 120°|
|IK rating IK08|
|IP rating IP68 (wet location submersible <2m)|
|Temperature range Installation: 0°C to 50°C / Operating: -40°C to 55°C|
|Connector type IP68 twist lock connector|
|Dimension 21mm x 11.5mm|
|Warranty 3-year return-to-base manufacturer warranty as standard. Talk to us to arrange longer periods|
Neon Flex DMX 24V
Neon Flex SPI 12V
|RGBW lumens output 214 lm/m||RGBW lumens output 246 lm/m|
|Control protocol DMX||Control protocol SPI – UCS8904|
|Input voltage 24V DC||Input voltage 12V DC|
|Power consumption 18W/m||Power consumption 17W/m|
|LED count 70 LEDs/m||LED count 60 LEDs/m|
|Pixel quantity 10 pixels/m||Pixel quantity 20 pixels/m|
|LED per pixel unit 7 LEDs||LED per pixel unit 3 LEDs|
|Pixel unit length 100mm||Pixel unit length 50mm|
|Max run length Single feed: 8m / Double feed 16m||Max run length Single feed: 4m / Double fed 8m|
For ease of installation, we offer a range of aluminium extrusions specifically designed to fit our Neon Flex. For surface-mounting or recessed applications, these are available in linear lengths as well as a special form that can be shaped into curves with diameters as tight as 3.15in/80mm.
We also have a range of system accessories to suit your needs, including 3-pin male or female connectors and power injector cables. Refer to the data sheets below for more information on mounting and cabling options.
