Ethergate MK3
US $ 550




Ethernet to dual DMX

DMXEthergate Mk3 has dual DMX ports, supports multiple protocols and can be easily configured using any web browser thanks to the built-in web-server. The new interface is easy to use, allows many possible options and lets you configure the unit as needed.

Multiple Protocol Support

  • Art-Net 1/2/3
  • sACN
  • ESP
  • RDM Over Art-Net

Features

  • Web-based configuration
  • Dual DMX: 2 input, 2 output or 1 in 1 out ports
  • Supports Art-Net, sACN, and ESP.
  • Supports either LTP or HTP Merging (upto 2 sources)
  • Supports RDM Over Art-Net (controller)
  • Broadcast or Unicast (Input mode)

Hardware

  • fits into a robust metal 9.5 inch 1 Unit rack.
  • Two units can be mounted side by side
    to form a standard 19 inch rack.
  • 2x DMX 5pin XLR connectors
  • IEC power connector
  • 10/100 Ethercon RJ45 Ethernet
  • in-built power supply (iput 90 to 260V AC)

Recommended App: D-PRO

  • D-PRO 2U is a software based lighting controller which plays well with a host of different professional level hardware devices from ENTTEC.
  • It has plenty of advanced features for the most demanding lighting professional applications
  • includes D-PRO Player, a touch screen firendly interface to easily control your cues.
  • An OSC controller (such as TouchOSC) can be used to remotely control D-Pro.
  • Windows and Mac OSX compatible

Recommended App: ELM

  • ELM : ENTTEC LED MAPPER provides total control over your LED system, regardless of shape and size.
  • Design your layout with vector-based objects for maximum precision and flexibility.
  • Load the media of your choice and begin playback as needed
  • Supports Spout and NDI
  • Supports RGB, RGBW, RGBA, RGBAW/RGBWA and White fixtures


Compatible 3rd Party Apps
