This priceless function speeds up installation time and works intuitively for installers, even if completely unfamiliar with DMX. Simply connect your CVC4s using PLink protocol, add power, and the CVC4s will all auto-address themselves. More advanced users can also address and monitor each CVC4 using RDM.
16-bit dimming is increasing in popularity and allows for users to have much finer control over their installation. The mode selection DIP switches allow users to choose between either 16 or 8-bit resolution. Simply pick your desired bitrate, select from either RGB or RGBW LED strip, then you’re all set!
Installing fuses to ensure that a system is safe takes up a great deal of time on site and can add to the space required per dimmer. To combat this, the CVC4 integrates a user-serviceable 20A ATO blade fuse that can be sourced easily and inexpensively to protect against dead shorts. If your installation draws less than 20A you can downrate the fuse to an appropriate level to suit your installation. To learn how to replace the CVC4’s fuse, check out our short instructional video in the download section below.
If the CVC4 ever reaches a high operating temperature, it will automatically reduce its output by 50% to prevent overheating and blink the LED Indicator red to notify the user until the device has sufficiently cooled.
Backward compatible with the CVC3 + DIN-LED4PX
Given the CVC4’s range of operating modes and flexibility to accept DMX or PLink data, it is fully backward compatible with the DINLED-4PX and CVC3.
Designed for longevity
MOSFETs are used to dim the LEDs wired to the CVC4’s output. During operation, it’s normal for these components to heat up. So that this device can run safely at a sustained temperature, our engineers have ensured that all MOSFETs are directly bonded to the metal casing in order to transfer heat outside the unit to better regulate its performance. Be wary of many cheap OEM products that do not allow these components to dissipate heat correctly, severely risking the safety and reliability of your project.
ENTTEC are proud to back up the confidence in our research, engineering and quality control with a 3-year manufacture defect warranty on this product.
